Off-axis Parabolic Mirrors perform well in the ultraviolet and visible light bands. The incident parallel light can be focused at a specific angle, and the collimation of the point light source and the focusing of the parallel beam will not produce spherical aberration and chromatic aberration. Mainly used in laser and medical treatment.


Material: Ag, Al, Ge, etc.

Diameter: φ5~φ300mm

Diameter tolerance: 0.00/-0.38mm

Surface quality: 40/20

Surface figure:PV<0.5μm

Roughness: RMS<λ/50

Off-axis angle: 15°, 30°, 45°, 60°, 90°

Coating: various coating solutions
