These Glan Thompson polarizers have been arranged to permit ther output of the s-polarized beam at 45 &deg from the straight through p-polarized beam. They provide high polarization purity and high transmission in the two emerging beams. These are useful if it is required to utilize both linear polarization states . They are mounted in a rectangular metal cell and surrounded with an absorbing compound.

 Material                           :    Calcite

Wavelength Range          :    Calcite: 350-2300 nm
Parallelism                       :     <1 arc Min.
Ectinction Ratio                :    Calcite:<5x105
Surface quality                 :    20-10
Beam Deviation               :    Typical: <3', High Precision: <3"
Wavefomnt Distortion      :    λ/4@633nm
Damage Threshold           :  > 500 MW/cm2
Coating                            :   Single MgF2 @1064
Mount                              :   Black Anodized Aluminium
